Menşe yeri:
China
Marka adı:
Promega
Sertifika:
CE
Model numarası:
Pro-LCM-80/100/150
Bize Ulaşın
video
Applicable Material
This machine can be usd to cut cloth,leather,wool,fur,acrylic,plexiglass,wooden board,plastic,resin,rubber,bamboo product,resin and other non-metal materials. According to different needs, customers can choose 80 watt, 100 watt and 150watt machine.
Adavantage
The machine is suitable for garment,leather,package and printing,advertisement decoration,building upholster,art gift,computer embroidery,paper product,acrylic board of plastic,middle density board etc.non-metal sheet precision cutting and other industries.
Technical Parameters
|
Laser Power |
50-150W(optional) |
|
Laser Type |
hermetic Co2 glass tube |
|
Power Supply |
AC220±10% 50HZ/AC 110±10% 60HZ |
|
Working Area |
900mm×600mm |
|
Max Moving Speed |
0---50mm/s |
|
Worktable |
honeycomb worktable/up&down worktable/aluminium knife(optional) |
|
Locating Precision |
＜0.01mm |
|
Min Shaping Character |
character:3×3mm,letter:2×2mm |
|
Operating Temperature |
5℃---35℃ |
|
Resolution Ratio |
≤4500dpi |
|
Control Configuration |
DSP |
|
DataTransfer Interface |
USB(offline) |
|
Svstem Environment |
WINDOWS 2000/WINDOWS XP/Vista/win7 |
|
Cooling Way |
water cooling and protection system |
|
Graphic Format Supported |
the files which CoreDraw,photoshop,AutoCAD can identify(BMP,GIF,JPEG,PCX,TGA,TIFF,PLT,CDR,DMG,DXF,PAT,CDT,CLK,DEX, CSL,CMX,AI,WPG,WMF,EMF,CGM,SVG,SVGZ,PCT,FMV,GEM,CMX) |
|
Compatible software |
CorelDraw,AutoCAD |
|
Cutting Thickness |
0---20mm(depends on different materials) |
|
Color Separation |
separation of cutting up to 256 colors |
|
Sloping Engraving |
yes,slope can be designed discretionarily |
|
Cuts off the Water Supply the Protection |
yes |
|
Machine Dimension |
1535*1200*1025 mm |
|
Package Dimension |
1700*1350*1250 mm |
|
New Weight |
280kg |
|
Gross Weight |
360kg |
|
Optional Parts |
high-grade cooling system/imported focus lens/dobble-head/cylinder rotary attachment/irregular rotary attachment |
